CAS NMNC sub-miniature load cell, 50kgf - 3t
CAS laod cell, NMNC mini load cell models: NMNC-50L, NMNC-100L, NMNC-200L, NMNC-500L, NMNC-1, NMNC-2, NMNC-3
⊙FEATURES
Sub-Miniature dimension
Compression application
Protection class IP65
⊙Material
Stainless steel
⊙Cable
Braided shield 4-wire round cable
⊙Ordering Information
| Model | Capacity |
| NMNC-50, NMNC-100, NMNC-200, NMNC-500L | kgf |
| NMNC-1, NMNC-2, NMNC-3T | tf |
| Max. capacity | kgf | 50, 100, 200, 500, 1tf, 2tf, 3tf | ||
| Rated output | Standard | mV/ V | 1.0 | |
| Option | 1.0 ± 10%R.O. | |||
| Zero balance | mV/ V | 0 ± 10%R.O. | ||
| Combined error Repeatability Temperature effect on Zero Value Output value | % % %/ 10℃ %/ 10℃ | ＜0.5 ＜0.5 0.028 0.015 | ||
| Excitation Recommended Maximum Resistance Input Output Insulation | V V Ω Ω MΩ | 10 15 400 ± 10 350 ± 5 ＞2,000 | ||
| Compensated temperature range Operating temperature range | ℃ ℃ | -10 to +40 -30 to +80 | ||
![NMNC[1].jpg](../upload/201704/1491802877334754.jpg "1491802877334754.jpg")
